Up for sale 800A Square D Heavy Duty Safety Switch H367N 600V is in perfect working condition! fully operational and functions as intended.
The Square D H367N is an 800-ampere, heavy-duty, fusible safety switch rated for 600V AC/DC. It features 3 poles, 4 wires, and a factory-installed neutral. This indoor NEMA 1 steel enclosure delivers heavy-duty power isolation with a maximum rating of 500 hp.
- Current Rating: 800 A
- Voltage Rating: 600 V AC / 600 V DC
- Number of Poles: 3 Pole
- Number of Wires / Neutral: 4-wire, 3-pole with 1 factory-installed neutral
- Fuse Type: Class L
- Short Circuit Current Rating (SCCR): 200 kA
- Enclosure Type: NEMA 1 (Indoor general purpose steel)
- Dimensions: 36.62 inches (Width) × 17.75 inches (Depth) × 69.13 inches (Height)
- Action Type: Single throw (quick-make, quick-break mechanism)
- Wire Size (Copper/Aluminum): 3/0 AWG to 750 kcmil
