Up For sale Fujikura FSM-60S Core Alignment Single Fiber Fusion Splicer  is in perfect working condition! fully operational and functions as intended.
The Fujikura FSM-60S Fusion Splicer is a core-alignment single-fiber tool featuring a 9-second splice time, 30-second tube heating, and an average splice loss of 0.02 dB for single-mode fiber
Specification
- Fiber types: Single-mode (G.652, G.657), multi-mode (G.651), DS (G.653), and NZDS (G.655).
- Cladding diameter: 80 µm to 150 µm.
- Coating diameter: 100 µm to 1,000 µm.
- Splice loss (typical): 0.02 dB (SM), 0.01 dB (MM), 0.04 dB (DS/NZDS).
- Splice/heating time: 9 seconds splice, 30 seconds heat cycle (60 mm sleeve)
-
- Dimensions: 136 mm W x 161 mm D x 143 mm H.
- Weight: 2.3 kg (with AC adapter) / 2.7 kg with battery.
- Durability: Shock, dust, and rain resistant; drop-tested to withstand a 30-inch drop.
- Operating conditions: -10°C to 50°C, 0 to 95% RH, and up to 5,000 meters elevation
