Hot sale PINES Model 2 Horizontal Tube Bender is in perfect working condition! fully operational and functions as intended.
The Pines Model 2 Horizontal Rotary Hydraulic Tube Bender features a maximum mild steel capacity of 3” OD x .109” wall, 2” Schedule 80 pipe, and a 2,000 PSI operating pressure. It typically includes a 7.5 HP to 10 HP motor, 180°+ max bend angle, and an approximate weight of 2,750 to 6,500 lbs depending on configuration
- Mild Steel Tube (Y.P. to 40,000 psi): Up to 3” OD x .109” wall
- Non-Ferrous Tube (Y.P. to 25,000 psi): Up to 3” OD x .188” wall
- Stainless Steel Tube (Y.P. to 60,000 psi): Up to 3” OD x .065” wall
- Schedule 80 Pipe: Up to 2” IPS
- Square/Rectangular Mild Steel: Up to 1 ½” x 3” x .148” wal
- Maximum Centerline Radius (Standard): 8” to 12” (varies by tooling setup)
- Operating Hydraulic Pressure: 2,000 PSI
- Drive Motor: 7.5 HP to 10 HP (3-phase electrical, typically 220V/440V/480V)
- Bending Head Rotation: Counter-clockwise (standard left-hand) or clockwise configurations
- Machine Weight: Approx. 2,750 lbs (base machine) up to 6,500 lbs (fully equipped with long mandrel extractor bed)
