Up For sale Fujikura FSM-60R Fusion Splicer is in perfect working condition! fully operational and functions as intended.
The Fujikura FSM-60R is a rugged, ribbon fiber fusion splicer (supporting 2 to 12 fibers) designed for field use, featuring a 9-second splicing time and automatic arc calibration. It includes a dual monitor position, 30-inch drop resistance, and a 30-second tube heater. The “USA Model” typically includes U.S.-compatible power components and English-language documentation.
Specification
- Tube heater: Built-in with 30 heating modes
- Heating time: ~40 seconds with Fujikura FP-04T sleeves
- Memory storage: Last 2,000 splice results
- Display/Magnification: Dual camera system with a TFT color LCD monitor and 35X to 90X magnification
-
- Fiber compatibility: Single-mode (G.652/G.657), multimode (G.651), DS (G.653), and NZDS (G.655)
- Fiber count: Single fiber, 2, 4, 5, 6, 8, 10, and 12-fiber ribbons
- Cladding diameter: 125 µm
- Typical splice loss: 0.05 dB (SM), 0.02 dB (MM), 0.08 dB (DS/NZDS) Splice time: 9 seconds typical (ribbon) / 20 seconds (standard single-mode)
